Optimizing my home and work network setup

After analyzing my network setup in a previous post, I decided it was time to dig deeper and optimize my network setup, both at home and at my office. With data-intensive workflows becoming more demanding - especially in areas like deep learning and computer vision - every millisecond and megabit counts.

Following is a detailed breakdown of the changes I made, the tools I used and the performance gains I achieved.

Baseline Measurements

At home I am using a less powerful network setup for obvious reasons:

Home Network

• ISP: DSL 250
• Router: FritzBox 7590 AX
• Ethernet: Directly connected to the router or
• Wi-Fi: FritzBox mesh network via a Fritz!Repeater 3000
• Speed test:
  • Ethernet: 183 Mbps download, 39 Mbps upload, 6.5 ms latency
  • Wi-Fi: 181 Mbps download, 37 Mbps upload, 9.8 ms latency

Work Network

At work I am running a bit more sophisticated setup:

• ISP: Vodafone Cable 1000
• Setup: 2.5 GBit Ethernet via CalDigit TS4 hub connected to my MacBook
• Server Rack: Includes a 1 GBit switch and a Proxmox application server
• Baseline Results (NetworkQuality):
  • Uplink: 889 Mbps
  • Downlink: 746 Mbps
  • Responsiveness (RPM): Medium, 487 RPM
  • Idle Latency: ~6 ms

Improvements and Their Impact

I did upgrade my server rack with a second-hand used 10G Ethernet switch from Netgear that I’ve bought for cheap online but first I did some experiments using the old (managed) switch first.

Leveraging Link Aggregation (LAG) at Work

I configured two Ethernet ports to share the network load (LAG) with the following results:

• Uplink: 1.152 Gbps (+29.6%)
• Downlink: 752 Mbps (+0.8%)
• Responsiveness: Medium, 387 RPM (slight reduction)
• Idle Latency: ~6 ms (unchanged)

While the uplink showed significant improvement, the downlink remained largely unchanged. Responsiveness slightly dipped, likely due to increased protocol overhead.

Upgrading to 10G Ethernet for Synology and Proxmox

At work, I added:

• A 10G module (E10G22-T1-Mini) network expansion module to my Synology RS422+
• A cheap 10G PCIe card for the Proxmox hypervisor

With these changes I got the following results:

Results (iperf3, Proxmox)

• Transfer: 2.74 GBytes
• Bitrate: 2.35 Gbits/sec

Reults (NetworkQuality, Proxmox)

• Uplink: 2 Gbps (+125%)
• Downlink:1 Gbps (+33.9%)
• Responsiveness: Medium, 942 RPM (+93.4%)
• Idle Latency: 6 ms (unchanged)

Optimizing MTU for Jumbo Frames

Adjusting the MTU from 1500 to 9000 allowed jumbo frames, increasing efficiency.

Impact on Responsiveness

• Before: 942 RPM
• After: 1778 RPM (+88.8%)

While throughput stayed constant, responsiveness doubled, indicating a significant reduction in network packet overhead.

Introducing the OWC 10G Thunderbilt 3 Ethernet Adapter

Upgrading my connection to the Proxmox server and Synology rack with the OWC adapter yielded dramatic results.

Results (iperf3)

• Proxmox:
  • Transfer: 9.64 GBytes
  • Bitrate: 8.288 Gbits/sec
• Synology:
  • Transfer: 9.54 GBytes
  • Bitrate: 8.19 Gbits/sec

Results (NetworkQuality)

• Proxmox:
  • Uplink: 1.3 Gbps
  • Downlink: 4.6 Gbps (+360%)
  • Responsiveness: Medium, 421 RPM
  • Idle Latency: 5.2 ms
• Synology:
  • Uplink: 4.2 Gbps (+373%)
  • Downlink: 1.7 Gbps (+70%)
  • Responsiveness: Medium, 360 RPM
  • Idle Latency: 4.8 ms

Home Network Upgrades with 2.5G Dongles

For my home setup, I added:

• A 2.5G USB Ethernet dongle for the Synology DS923+ and the CalDigit TS3 hub
• Adjusted internal PCI sharing for stable performance

Results (iperf3)

• Transfer: 2.28 GBytes
• Bitrate: 1.96 Gbits/sec

Results (NetworkQuality)

• Uplink: 641 Mbps
• Downlink: 1.433 Gbps
• Responsiveness: High, 3905 RPM (+>7x)
• Idle Latency: 4.9 ms

The dongle upgrade transformed my basement rack’s performance, especially for responsiveness and latency, despite hitting the throughout ceiling of the 2.5G connection.

Overall Performance Gains

Metric	Baseline (Work)	Final (Work)	Improvement
Uplink (Gbps)	0.889	4.2	+372.5%
Downlink (Gbps)	0.746	4.6	+516.2%
Responsiveness (RPM)	487	1778	+265%

Metric	Baseline (Home)	Final (Home)	Improvement
Uplink (Gbps)	183	641	+250%
Downlink (Gbps)	39	1443	+3581%
Responsiveness (RPM)	454	3905	+760%

Key Learnings and Next Steps

1. Jumbo Frames: Enabling an MTU of 9000 dramatically improves responsiveness without impacting throughput.
2. 10G Ethernet: Investments in 10G hardware pays of, especially for workloads like backups and Proxmox hypervisor.
3. PCI Optimization: Understanding internal bus sharing is crucial for stable performance.

Next, I plan to investiage further fine-tuning options, including QoS settings for prioritizing critical traffic and potential upgrades to fiber internal at home.
